This 4S 14.8V 10A Lithium battery Protection Board comes with over-charge, over-discharge, over-current and short circuit protection, for a variety of various shapes 3.7V lithium-Ion batteries. HX-4S-A01 is Small size, suitable for many requirements of high integration, low cost of the occasion, to meet a wide range of performance requirements to ensure that the battery pack is absolutely safe and reliable.
Applications:
- Small power inverter
- Massager battery pack
- LED lamp backup power
- Electronic products
- Solar street lamp battery pack
- Monitoring standby power supply.
Features:
- This protection board is suitable for 4 series Li-ion cell.
- Adopt a precision integrated circuit for fast and safe charging.
- Support overcharge protection, over-discharge protection, and short circuit protection.
- This product has gone through load and ageing test for quality assurance.
Package Includes:
1 x 4S 10A 18650 Lithium Battery Protection Board
Specifications:
| Model | HX-4S-A01 |
| Charging voltage | 16.8V-17V |
| Overvoltage range | 2.3~3.0V±0.05V |
| Upper working current | 8 to 10A |
| Internal resistance | less than 100mΩ |
| Effective life | more than 50,000 hours |
| Length (mm) | 72 |
| Height (mm) | 17.8 |
| Weight (gm) | 3 |
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 282.02 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
4S 10A 18650 Lithium Battery Protection Board
- Product Code: EC-7191
- Availability: 163
-
Rs.132.00
- (Excluding 18% GST)
