The Runcam Phoenix 2 Joshua Bardwell Edition is the new successor of the previous Runcam Phoenix 2 editions. The Joshua Bardwell Edition comes with a UART control mode, which will be displayed at the top left corner of your screen.

Just like the last editions, this camera works great in the day and night time due to its f/2.0 big aperture. With upgraded CPU and upgrade 1/2 high-performance image sensor, the RunCam Phoenix 2 produces vivid high-resolution pictures rich yet natural color.

The high quality 6 layers of glass lens have an f/2.0 aperture, which brings less red flare and less purple fringing effect. This camera also has less shimmer than some FPV cameras.

Features :

1. New upgraded CPU for better performance
2. High quality 6 layer glass lens for better picture
3. PAL/NTSC & 4:3/16:9 Switchable
4. Supports Image Mirror & Flip
5. Low latency, high performance
6. Excellent low light performance

Package Includes:

• 1 x RunCam Phoenix 2 Joshua Bardwell Edition
• 1 x ABS Bracket
• 1 x 6pin FPV Silicone Cable
• 1 x Screw Set
• 1 x Manual

Specifications :-

Model	RunCam Phoenix 2: Joshua Bardwell
Image Sensor	1/2" COMS Sensor
Min. Illumination	0.001Lux@1.2F
Operating Voltage (VDC)	DC 5-36V
Max. Operating Current (mA)	200 mA@5V ; 85 mA@12V
Electronic Shutter Speed	Auto
Lense Viewing Angle (FOV)	2.1 mm (M12) FOV155 (4:3)
Horizontal Resolution (TVL)	1000
Screen Format	4:3 / 16:9 Switchable
Max Gain	Auto
S/N Ratio (dB)	>50dB (AGC OFF)
Signal System	PAL/NTSC Non Switchable
Housing Material	ABS
Length (mm)	19
Width (mm)	19
Height (mm)	20
Net weight (gm)	9
