HLK PM03 is an Open Frame Hi Link Power Module HLK PM03L is a small-volume, high-efficiency AC DC power module supply designed by Shenzhen Hi-Link Electronics Co.Ltd. Available in India at Rajguru Electronics. It has the advantages of global input voltage range, low-temperature rise, low power consumption, high efficiency, high reliability, and high safety isolation.
Note: The image may vary in terms of size, shape, and color.
Features:
1. HLK pm03l open frame hi link power module meets UL, CE requirements,
2. Ultra-thin, ultra-small
2. All voltage input (AC: 90 ~ 265V)
3. Low ripple and low noise
4. Output overload and short circuit protection
5. High efficiency, high power density
6. Hlk Pm03l Open Frame Hi Link Power Module is designed to meet the requirements of EMC and Safety Test
7. Low power consumption, environmental protection, no-load loss <0.1W
8.100% load aging and testing
Specifications:
- Input Voltage: 100-240V AC
- Input Frequency: 50-60Hz
- Output Voltage: 3.3V
- Output current: 600mA
- Power: 3W
- Output peak current: 1000mA
- Maximum Input current: 0.2A
- Efficiency: 70%
- In-built short circuit and over-current protection.
Package Includes:
1 x HLK PM03L OPEN FRAME Hi Link Power Module
Attachments :
Download| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 0 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
HLK PM03L OPEN FRAME Hi Link Power Module
- Product Code: EC-18542
- Availability: 22
-
Rs.158.00
- (Excluding 18% GST)
