Hongfa 6V 16A DC HF115F-Q/006-1D 6-Pin SPST Power Relay with Metal Holder Attached
Features:
- Ambient temperature up to 125 °C
- 5kV dielectric strength (between coil and contacts)
- Low height: 15.7mm
- Creepage distance >8mm
- Meeting VDE 0700, 0631 reinforce insulation
- UL94, V-0 flammability class
- Product in accordance to IEC 60335-1 available
- Class F insulation
- Environmental friendly product (RoHS compliant)
- Outline Dimensions : (45.0 x 12.7 x 15.7) mm
Specifications:
- Type : HF115F-Q/006-1D
- Switching Current (A, Res. load) : 16A
- Contact arrangement : 1 Form A
- Contact material : AgSnO2
- Construction : Flux sealed
- Coil voltage : 6
- Creepage Distance : 8mm
- Coil Power : 0.4W
- Unit Weight : 16gm
Package Includes:
1 x Hongfa 6V 16A DC HF115F-Q/006-1D 6-Pin SPST Power Relay with Metal Holder Attached
| Brand/Manufacturer | |
| Country Of Origin | |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 105.02 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
Hongfa 6V 16A DC HF115F-Q/006-1D 6-Pin SPST Power Relay with Metal Holder Attached
- Product Code: EC-10448
- Availability: 1265
-
Rs.95.00
- (Excluding 18% GST)
