Key Specifications:-

• Output Voltage-Channel 1         5 VDC
• Output Voltage-Channel 2         15 VDC
• Output Voltage-Channel 3         -15 VDC

• Output Current-Channel 1         10A
• Output Current-Channel 2         4.5A
• Output Current-Channel 3         1A

• Number of Outputs                   3 Output
• Output Power                           132.5 W
• Type                                        Enclosed Type Triple Output
• Features                                 Standard

• Series                                 RT (Reliable)

• Mechanical Form                 Enclosed

• Warranty                                 3 Years Warranty

• IP Level                                 Non-Waterproof

• Input Voltage                         88 VAC to 132 VAC / 176 VAC to 264 VAC (Selected by Switch), 125 VDC to 373 VDC


Features:-

• Universal AC input / Full range
• Protections: Short circuit / Overload / Over voltage
• Cooling by free air convection
• LED indicator for power on
• 100% full load burn-in test
• All using 105°C long life electrolytic capacitors
• Withstand 300VAC surge input for 5 second
• High operating temperature up to 70°C
• Withstand 5G vibration test
• High efficiency, long life and high reliability
• 3 years warranty

Specifications:-

Manufacturer:          MEAN WELL

Output Voltage-Channel 1:          5 VDC

Output Voltage-Channel 2:          15 VDC

Output Voltage-Channel 3:          -15 VDC

Number of Outputs:          3 Output

Output Power:          132.5 W

Open Frame/Enclosed:  Enclosed

Input Voltage:          88 VAC to 132 VAC / 176 VAC to 264 VAC (Selected by Switch), 125 VDC to 373 VDC

Input Current         2A/230VAC, 3A/115VAC

Output Current-Channel 1:  10 A

Output Current-Channel 2:  4.5 A

Output Current-Channel 3:  1 A

Operating Temperature: -25 TO +70 DEG CEL.

Voltage Adjustable Range:         4.75 ~ 5.5V

Frequency:         47 TO 63Hz

Protection:         Short circuit / Overload / Over voltage

Industry:                  Commercial

Mounting Style:          Chassis

Length:                  199 mm

Width:          98 mm

Height:                  38 mm

Safety Standards:  UL62368-1, TUV EN62368-1 approved

Series:                  RT-125

Model:         RT-125C

Brand:          MEAN WELL

EMC Emission:          Compliance to EN55032 (CISPR32) Class B, EN61000-3-2,-3, EAC TP TC 02

Unit Weight:          700 g
