TheT-Motor Brushless Motor AK70-10 is a highly integrated and high-torque module. The module weighs only 521 g, thin as 50.2 mm combined with efficiency and dynamic. This motor combines with a planetary gear solution and uses a 10:1 reduction ratio.
Features:
- Offers highly integrated and high torque module
- Reducer and controller in one
- Applied to an exoskeleton, quadruped robotic dog
- Easy configuration with RUBIK Link
- Interface: 12Bit encoder and UART/CAN
- Ke(V/rpm): 0.01
- Km(Nmh/w): 0.19
- Kt(Nm/A) 0.095
- Kv(RPM/V): 100
Package Includes:
1 x T Motor AK70-10 KV100 Brushless Robot Motor(Without Driver)
| Brand/Manufacturer | Generic |
| Country Of Origin | China |
| Packer / Importer Address | Constflick Technologies Limited, Building No 13 and 14, 3rd Floor, 2nd Main, Siddaiah Road, Bangalore, Karnataka - 560027 India. |
| MRP | Rs. 0 (Inclusive of all Taxes) |
* Product Images are shown for illustrative purposes only and may differ from actual product.
T Motor AK70-10 KV100 Brushless Robot Motor(Without Driver)
- Product Code: EC-22356
- Availability: 1
-
Rs.47424.00
- (Excluding 18% GST)
