Introducing the Waveshare NAS Multi-functional Mini-Computer, a versatile and compact computing solution meticulously designed to harness the power of the Raspberry Pi Compute Module 4. This innovative device is engineered to empower enthusiasts, developers, and small-scale enterprises with a powerful, multi-purpose computing platform, making it ideal for a wide range of applications.

At the core of this mini-computer lies the Raspberry Pi Compute Module 4, which boasts enhanced processing capabilities, improved memory, and enhanced I/O options. This integration allows you to leverage the full potential of the Raspberry Pi ecosystem while enjoying a compact and efficient form factor

Note: Raspberry Pi Compute Module 4(NOT Included)

Features:

1. All-in-one Mini-Computer, mainly designed for home, small home office, etc.
2. Provides a simple and easy-to-use solution, no expert knowledge of networking and storage systems required
3. Onboard 2 M.2 M KEY slots for installing NVME Solid State Drives
4. Onboard MINI PCIE connector for installing 4G module
5. 2 HDMI 4K output interfaces
6. Onboard USB3.2 ports, IR receiver, RTC, dual Gigabit Ethernet connectors, 3.5mm jack, etc.
7. CM4 Socket: Suitable for all variants of Compute Module 4

Specifications:

1. Networking: Gigabit Ethernet RJ45 connector 2 (Original Network port ETH0, and PCIE extended Network port ETH1) , miniPCIE connector, supports 4G module (USB protocol, can not support PCIE protocol) , Nano-SIM card slot supports standard Nano-SIM card for 4G/3G/2G Internet access
2. M.2: Dual NVME Solid State Drives slots (compatible with 2230, 2242, 2260, 2280)
3. USB: USB 3.2 Gen1 (5Gbps) port 2
4. CSI Camera: MIPI CSI-2 camera port 2, 15pin 1.0mm FPC connector
5. HDMI: HDMI 2, supports 4K 30fps output
6. Audio: 3.5mm earphone/mic jack
7. RTC: Real-time clock with battery socket and ability to wake Compute Module 4
8. TF Card Slot TF card socket for Compute Module 4 Lite (without eMMC) variants
9. Power Input Type-C (5V 4A)
10. Dimensions: 128 122 36mm

Package Includes:

1 x Waveshare NAS Multi-functional Mini-Computer Designed for Raspberry Pi Compute Module 4
